  • International Ground Station helps a user to directly download the data at their Ground Station.
  • When a user is having a Ground Station, it would be enabled with certain hardware and Software, so that the station can directly receive and process data and generate the data products.
  • Advantages of having IRS-International Ground Station.
    • Direct downloaded of data and hence near real time data availability.
    • User can give the tasking requirement and it is imaged on priority and downloaded to the user ground station.
    • User can generate different data products.
    • User can disseminate the data to any number of users.
  • For continuous data requirement, it is ideal to establish IGS for IRS satellite.
  • Initial investment would only for Hardware and Software at a reasonable price.  Further, based on the access, user needs to pay only the access fee.
  • If the user does not have a ground station, Antrix can build a Data Reception Ground Station for the user at his premises on Turn-key basis.
Basic Software packages required at User Stations are:
S. No. Name of Software
1 Data Archival and Quick Look Browse (DAQLB)
2 Data Product Generation system (DPGS)
3 Ancillary Data Processing (ADP)
4 Product Quality Check System (PQC)
5 Browse Archival Server System (BASS)
Basic Hardware required at User Stations are:
S. No. Name of Software
1 Advanced Front-End Hardware (AFEH)
2 Time Code Translator (TCT)
ANTRIX/ ISRO will carry out a detailed study and workout actual requirements at the user ground stations.
Resourcesat Series:
    • The satellites in this series are primarily meant for Natural Resources Inventory, Monitoring applications in Land and Water.
    • Currently Resourcesat-2 and Resourcesat-2A are in Orbit. They are unique satellites having multi-tier imaging capability from the same platform. Resourcesat-2/2A satellite has three cameras.
    • Products to International Users by ANTRIX:
Cameras Specification Products Image
LISS-4
  • Spatial: 5.8 m
  • Spectral: 3 Bands (B2, B3, B4)
  • Radiometry: 10 bit
  • Swath: 70 Km
Georeferenced Products
  • 23.5 km X 23.5 km
  • 70 km x 70 km
LISS-3
  • Spatial: 23.5 m
  • Spectral: Bands (B2, B3, B4, B5)
  • Radiometry: 10 bit (VNIR) & 7 bit (SWIR)
  • Swath: 141 km
Georeferenced Products
  • 141 km X 141 km
AWiFS
  • Spatial: 56 m at nadir Spectral: 4 Bands (B2, B3, B4, B5)
  • Radiometry: 12 bit
  • Swath: 740 Km
Georeferenced Products
  • 740 km X 740 km
Note: B2: 0.52 – 0.59 µm; B3: 0.62 – 0.68 µm; B4: 0.77 – 0.86 µm; B5: 1.55 – 1.70 µm
Basic Software packages required at User Stations are:
S. No. Name of Software
1 Data Archival and Quick Look Browse (DAQLB)
2 Data Product Generation system (DPGS)
3 Ancillary Data Processing (ADP)
4 Product Quality Check System (PQC)
5 Browse Archival Server System (BASS)
Basic Hardware required at User Stations are:
S. No. Name of Software
1 Advanced Front-End Hardware (AFEH)
2 Time Code Translator (TCT)
ANTRIX/ ISRO will carry out a detailed study and workout actual requirements at the user ground stations.
Cartosat Series:
  • The satellites in this series provide high/very high resolution satellite imagery required for Cartographic/ large scale mapping applications.
  • Currently, Cartosat-1 (Along Track Stereo Mission with two cameras – PAN (Fore and AFT) and Cartosat-2S (with two cameras) are in orbit.
  • Products to International Users by ANTRIX:
Satellite Specification Products Image
Cartosat-1
  • Spatial: 2.5 m
  • Spectral: PAN 0.50 – 0.85µm
  • Radiometry: 10 bit
  • Swath: 30 km
Mono Georeferenced Products
  • 27.5 km X 27.5 km
Stereo Orth kit Products
  • 27.5 km X 27.5 km
Cartosat-2S PAN
  • Spatial: 0.65 m
  • Spectral: PAN 0.50 – 0.85 µm
  • Radiometry: 11 bit
  • Swath: 10 km
Georeferenced Products
  • 10 km X 10 km
Cartosat-2S MX (Multi-Spectral)
  • Spatial: 1.60 m
  • Spectral: 4 Bands (B1, B2, B3, B4)
  • Radiometry: 11 bit
  • Swath: 10 km
Georeferenced Products
  • 10 km X 10 km
Note: B1: 0.45 – 0.52 m; B2: 0.52 – 0.59 m; B3: 0.62 – 0.68 m; B4: 0.77 – 0.86 m
Basic Software packages required at User Stations are:
S. No. Name of Software
1 Data Archival and Quick Look Browse (DAQLB)
2 Data Product Generation system (DPGS)
3 Ancillary Data Processing (ADP)
4 Product Quality Check System (PQC)
5 Browse Archival Server System (BASS)
Basic Hardware required at User Stations are:
S. No. Name of Software
1 Advanced Front End Hardware (AFEH)
2 Time Code Translator (TCT)
ANTRIX/ ISRO will carry out a detailed study and workout actual requirements at the user ground stations.
Oceansat Series:
  • The satellites in this series are meant for the ocean and atmospheric studies.
  • Currently, Oceansat-2, SARAL (Joint Mission with CNES), Megha-Tropiques (Joint Mission with CNES) and are in Orbit.
  • The data from OCM sensor of Oceansat-2 is made available to International Users by ANTRIX.
Camera Specification Products
Ocean Colour Monitor (OCM-2)
  • Spatial: 360m along track 236m across track
  • Spectral: 8 bands operating in 402 – 885 nm range
  • Radiometry: 12 bit
  • Swath: 1420 km
Georeferenced Products
  • 1420 km X 1420 km
Basic Software packages required at User Stations are:
S. No. Name of Software
1 Data Archival and Quick Look Browse (DAQLB)
2 Data Product Generation system (DPGS)
3 Ancillary Data Processing (ADP)
4 Product Quality Check System (PQC)
5 Browse Archival Server System (BASS)
Basic Hardware required at User Stations are:
S. No. Name of Software
1 Advanced Front-End Hardware (AFEH)
2 Time Code Translator (TCT)
ANTRIX/ ISRO will carry out a detailed study and workout actual requirements at the user ground stations.
